Homelab Kubernetes, Episode 1: Installing k3s

This is part of a series on building a self-hosted Kubernetes homelab. Start with the series intro if you haven't already.

Before any service in this series can run, you need a Kubernetes cluster. This post covers installing k3s, creating the namespace structure that everything else depends on, and verifying that kubectl is working correctly.

Prerequisites

Before running anything here, you need:

• A Linux server up and running. This guide uses Ubuntu 24.4.
• A static IP assigned to your server, outside your router's DHCP range
• The /data directory created (covered in the series intro)

You should also install Helm now. Later episodes use it to install MetalLB and Traefik.

curl https://raw.githubusercontent.com/helm/helm/main/scripts/get-helm-3 | bash

Helm is the Kubernetes package manager. It installs pre-packaged applications into your cluster the same way apt installs software on Ubuntu.

Four Concepts You'll Use Constantly

Before looking at any YAML, here are the Kubernetes terms that come up in every episode.

Pod: The smallest unit in Kubernetes. A pod runs one or more containers. When you deploy a service, Kubernetes creates a pod for it.

Deployment: A Kubernetes object that says "keep N copies of this pod running." If a pod crashes, the Deployment restarts it automatically.

Service: A stable network address for a set of pods. Pods can restart and get new internal IP addresses. A Service gives them a consistent name that other services can reach.

Namespace: A logical grouping for related resources. All the network tools (Pi-hole, Tailscale, Cloudflared) go in the network namespace. All media services go in the media namespace. Namespaces let you manage groups of services together.

Manifest: A YAML file that describes a Kubernetes object. You apply manifests with kubectl apply -f <filename>. Kubernetes reads the file and creates or updates the objects described in it.

IngressRoute: A Traefik-specific object that maps a hostname (like pihole.example.com) to a Service running in the cluster. The Traefik episode covers this in detail.

Create the Namespace Manifest First

Create the namespace manifest before installing k3s. This file defines every namespace you'll use across the entire series.

Create /data/manifests/namespace.yaml:

apiVersion: v1
kind: Namespace
metadata:
  name: network
---
apiVersion: v1
kind: Namespace
metadata:
  name: productivity
---
apiVersion: v1
kind: Namespace
metadata:
  name: media
---
apiVersion: v1
kind: Namespace
metadata:
  name: tools
---

Why write this as a separate file? If you put namespace definitions inside each service's manifest, running kubectl delete -f pihole.yaml would delete the network namespace along with Pi-hole. That would also take down Tailscale and Cloudflared, which live in the same namespace. Keeping namespaces in a separate file prevents that.

Install k3s

Check the k3s releases page for the latest stable version before running this. Replace v1.31.0+k3s1 with the current release.

export SERVER_IP=192.168.1.x   # Replace with your server's static IP

curl -sfL https://get.k3s.io | INSTALL_K3S_VERSION="v1.31.0+k3s1" sh -s - \
  --cluster-init \
  --node-ip "$SERVER_IP" \
  --advertise-address "$SERVER_IP" \
  --disable traefik \
  --disable servicelb \
  --disable local-storage \
  --write-kubeconfig-mode 0644

This command downloads the k3s installer and runs it with specific flags. Here's what each flag does:

The install takes about 30 seconds. Wait for it to return to a prompt before continuing.

Configure kubectl

k3s writes a kubeconfig file to /etc/rancher/k3s/k3s.yaml. This file contains the credentials and endpoint for talking to your cluster. Copy it to your home directory so kubectl can find it without sudo:

mkdir -p ~/.kube
cp /etc/rancher/k3s/k3s.yaml ~/.kube/config
chown $USER:$USER ~/.kube/config

Then add KUBECONFIG to your shell profile so it's set automatically on login:

echo 'export KUBECONFIG=~/.kube/config' >> ~/.bashrc
source ~/.bashrc

Verify the Cluster

Check that the node is ready:

kubectl get nodes

You should see your server listed with a status of Ready. If the status shows NotReady, wait 30 seconds and try again. k3s takes a moment to fully initialize after install.

Check the system pods:

kubectl get pods -n kube-system

All pods should show Running or Completed. The coredns pod handles DNS inside the cluster. The metrics-server pod collects resource usage data.

Apply the Namespace Manifest

Now apply the namespace file you created earlier:

kubectl apply -f /data/manifests/namespace.yaml

Verify the namespaces exist:

kubectl get namespaces

You should see all the namespaces from the manifest alongside the default Kubernetes namespaces (default, kube-system, etc.).

Common Problems

Don't mix k3s and a separate kubectl binary. k3s installs its own kubectl at /usr/local/bin/kubectl. If you install another version via snap or apt, they may conflict. Use the one k3s installed.

--cluster-init is permanent. This flag switches the data store from SQLite to embedded etcd. There's no migration path. If you installed without --cluster-init and want it, you'll need to uninstall and reinstall k3s. The uninstall script is at /usr/local/bin/k3s-uninstall.sh.

If kubectl get nodes hangs, check that k3s.service is running:

sudo systemctl status k3s

Summary

You now have a running k3s cluster with all namespaces in place. Every service in this series deploys into one of these namespaces.

In Episode 2, you'll install MetalLB so that Kubernetes services can receive real IP addresses on your LAN. That's required before Traefik can work.
